Special aluminum alloy mould block with anti-adhering treatment; cooling air, cooling water and vacuum channel inside of mould block ensure good forming structure of pipe and speed.
The cutting unit can cut pipe in right position by tracking switch. The high quality alloy knife and clamp tools can satisfy different cutting.
The line adopts OMRON or MITSUBISHI PLC computer control system with touch screen interface, which guarantee automatic and reliable operation.
HDPE/PVC Double-wall corrugated pipe is one kind of outer annular corrugated, smooth wall structure of a new plastic pipe.Compared with metal, ceramic, concrete and other pipes, double-wall corrugated pipe has many advantage such as lower weight, lower cost, erosion resistance, smooth inside-wall, high intensity, abrasion resistance, easy connection and so on. Its weight was significantly lower than the flat-wall pipe or concrete pipe, and connection, construction convenient, the cost of a significant reduction in pipe and increase the market competitiveness of the pipe. So it is used widely for sewerage and drainage system(larger diameter), cable protection system(smaller diameter), etc.

Main parameter

Model/parameter	Pipe diameter Range(mm)	Extruder model	Max. output (kg/h)	Speed of Forming system (m/min)	Number of module blocks (pair)	Belling method	Total installed power(kw)
FBWG-160 PE	90-160mm	FSJ-50X30A FSJ-65X30A	120 180	1-6	41	/	150
FBWG-250 PE	110-250mm	FSJ-50X30A FSJ-65X30A	120 220	1-4	41	On-line belling	200
FBWG-500 PE	200-500mm	FSJ-65X30A FSJ-80X30A	220 400	0.3-3	41	On-line belling	260
FBWG-1000 PE	500-1000mm	FSJ-90X30B FSJ-120X30B	500 900	0.1-2	41	On-line belling	670
